Description:
This manlid seal combines the resilience and compression set resistance of EPDM rubber with the outstanding chemical resistance of PTFE.
The seal's rectangular elastomeric core is enveloped on three sides: top and bottom sealing faces and the inside diameter with 100% virgin PTFE.
Prime Features:
Excellent chemical resistance.
Withstands repeated opening/closing cycles without loss of sealing integrity.
Chemical properties
The PTFE envelope makes the sealing faces and inside diameter chemically inert to media in the range pH 0-14 including all bulk liquid cargoes in all IMO classes.
The virgin PTFE is non-absorbent, non-tainting, and hygienic for use with foodstuffs and edible oils.
Service capabilities:
Tank maximum pressure: 4bar
Maximum temperature: +110°C
Minimum temperature: -25°C
Technical Datas: |
|
|
|
|
|
SUNPASS CODE |
TYPE |
SIZE |
|||
EP00001 |
DN500 |
(14MM *12MM) SECTION*486MM INNER DIA. |
|||
EP00002 |
DN500 |
(14MM *14MM) SECTION*490MM INNER DIA. |
|||
EP00003 |
DN300 |
(14MM *10MM) SECTION*294MM INNER DIA. |
