Home / News / Super Tank Llid Seal Super Tank Seal Manlid Parts ISO Tank Container Parts From SUNPASS

Super Tank Llid Seal Super Tank Seal Manlid Parts ISO Tank Container Parts From SUNPASS



Description:

This manlid seal combines the resilience and compression set resistance of EPDM rubber with the outstanding chemical resistance of PTFE.

The seal's rectangular elastomeric core is enveloped on three sides:  top and bottom sealing faces and the inside diameter with 100% virgin PTFE.



Prime Features:

Excellent chemical resistance.

Withstands repeated opening/closing cycles without loss of sealing integrity.

Chemical properties

The PTFE envelope makes the sealing faces and inside diameter chemically inert to media in the range pH 0-14 including all bulk liquid cargoes in all IMO classes.

The virgin PTFE is non-absorbent, non-tainting, and hygienic for use with foodstuffs and edible oils.





Service capabilities:

Tank maximum pressure: 4bar

 Maximum temperature: +110°C

Minimum temperature: -25°C





Technical Datas:











SUNPASS CODE

TYPE

SIZE

EP00001

DN500

(14MM *12MM) SECTION*486MM INNER DIA.

EP00002

DN500

(14MM *14MM) SECTION*490MM INNER DIA.

EP00003

DN300

(14MM *10MM) SECTION*294MM INNER DIA.



For more details, please visit https://www.sealings.cn/product/iso-tank-container-spare-parts-product/manlid-and-accessory/super-tanktyt-llid-seal.html
