SUNPASS Steel Strip for Spiral Wound Gasket is a special semi-metallic gasket of great strength and resilience, therefore they are suitable for use under heavy operating conditions. It is made of Stainless Steel Metal Strip Tape for Inner and Outer Ring of Spiral wound gasket. The materials can be SS304, SS 316L, SS 321, SS 317L, SS 31803, Carbon Steel, Monel 400, Ti, Inconel 600, Hast.C/B, Zr702, etc.
| Items | Data | ||||||
| Material | 304 SS | Carbon Steel | 316L SS | Nickel-200 | Incoloy-800 | Inconel-600 | |
| Hardness (HB) | 130-180 | 120 | 130-180 | / | / | 150 | |
| Temperature (°C) | -195~760 | -40~540 | -100~760 | -195~760 | -100~870 | -100~1090 | |
| Tensile Strength (MPa) | 540 ~ 750 | ||||||
| Proof Stress (MPa) | 230 Min | ||||||
| Elongation A50 mm | 45 Min % | ||||||
| Width | 6-40mm | ||||||
| Thickness | 2.0-4.0 mm | ||||||
It is resistant to seawater and steam at high temperatures and excellent resistance to rapidly flowing brackish water or seawater.
It has excellent resistance to stress corrosion cracking in most freshwaters and is particularly resistant to hydrochloric and hydrofluoric acids when they are de-aerated.
Sealing Flange Joints, Manhole and Handhole Covers, Tube Covers, Boilers, Heat Exchangers, Pressure Vessels, Pumps, Compressors and Valves
Simply you can wholesale Steel Strip for Spiral Wound Gasket direct from manufacturers.
SUNPASS SEALING i a leading manufacturer in Sealing and Insulation in China. Production & Service 7*24 . Sunpass is a famous Chinese brand and Steel Strip for Spiral Wound Gasket suppliers known by the world since 2000.
