EspañolTOP SEALING MICA SHEET are designed for use in extreme conditions and have very good properties like heat retarding, flame resisting, low thermal conductivity, good electrical insulation, high mechanical strength and non toxic.
TOP SEALING MICA SHEET are designed for use in extreme conditions and have very good properties like heat retarding, flame resisting, low thermal conductivity, good electrical insulation, high mechanical strength and non toxic.
| Property | Data | |
| Temperature Range (°C) | Up to 1000°C | |
| Pressure Range (bar) | Up to 5 bar | |
| Density (g/cm3) | 2.1 g/cm3 | |
| Thermal Conductivity (w/m) | 0.3 | |
| Compressive strength at 20°C (N/mm2) | ≥400 | |
| Flexural strength (N/mm2) | ≥230 | |
| Tensile Strength (Mpa) | 20 | |
| Recovery | 35% | |
| Misture Content | < 3% | |
| Weight Loss @ 550°C for 4 Hrs | < 1 % | |
| Water Absorption after 24 hrs | < 0.50 % | |
| Ignitiaon loss @ 800°C | < 5% | |
Simply you can wholesale MICA SHEET direct from manufacturers.
For Arc chutes, Bus bar support, Resistor bank, molding plates, Dynamic braking resistors, furnace lining, resistor heat dissipaters, Insulation of platen in heated hydraulic presses, Induction furnace.
SUNPASS SEALING i a leading manufacturer in Sealing and Insulation in China. Production & Service 7*24 . Sunpass is a famous Chinese brand and MICA SHEET suppliers known by the world since 2000.
