NON-ASBESTOS RUBBER SHEET

Description:

TOP SEALING NON-ASBESTOS RUBBER SHEET Made of special asbestos free heat-resisting Fibre, heat-resisting packing material and nature rubber compound heating and compression molding it. Tenglong / Sunpass non asbestos sheets are designed for a wide range of applications in petrochemistry, chemistry, industrial and other equipment requiring specific sealing solutions. A comprehensive range of grades is available covering a wide spectrum of applications.

Detail Image

Product Details

Max. Lasting Temperature	Max. Short-term Temperature	Max. Pressure	Compressibility	Recovery	Spec. Leakage Rate	Flexibility
150℃/302℉	200℃/392℉	60 bar	5 – 15%	≧45%	≈0.1 mg/(s.m)	No cracks and breaks
200℃/392℉	360℃/680℉	80 bar	5 – 15%	≧50%	≈0.1 mg/(s.m)
250℃/482℉	400℃/752℉	100 Bar	5 – 15%	≧50%	≈0.06 mg/(s.m)
300℃/572℉	400℃/752℉	100 Bar	5 – 15%	≧50%	≈0.04 mg/(s.m)
350℃/662℉	450℃/842℉	120 bar	5 – 15%	≧50%	≈0.04 mg/(s.m)
400℃/752℉	450℃/842℉	130 bar	5 – 15%	≧60%	≈0.02 mg/(s.m)
450℃/842℉	480℃/896℉	130 bar	5 – 15%	≧60%	≈0.04 mg/(s.m)

More Styles

Application Data

Advantages

Video

Comparison Vision

Max. Lasting Temperature	Weight	Thickness	Reinforcement	Coating	Size	Color
150℃/302℉	118.56lb/ft3 (1.9g/cm3)	0.02-0.3inch (0.5-6mm)	Stainless Steel	Graphite, Silicon Rubber	1270 x 1270mm, 1270 x 3810mm, 1500 x 1000mm, 1500 x 1350mm, 1500 x 1500mm, 1500 x 2000mm, 1500 x 3000mm, 1500 x 4100mm, 1500 x 4600mm, 2700 x 3810mm.	Red, Green, Yellow, Blue, Black, Grey
200℃/392℉
250℃/482℉
300℃/572℉
350℃/662℉
400℃/752℉
450℃/842℉

Simply you can wholesale NON-ASBESTOS RUBBER SHEET direct from manufacturers.

Professional Manufacturer

SUNPASS SEALING i a leading manufacturer in Sealing and Insulation in China. Production & Service 7*24 . Sunpass is a famous Chinese brand and NON-ASBESTOS RUBBER SHEET suppliers known by the world since 2000.
