TOP SEALING Spiral Wound Gaskets are made up of a preformed thin metallic strip combined with a soft sealing composite material. These components are carefully wound together under pressure to activate the sealing element, causing it to function like a spring when compressed between two flange faces. Depending on the specific application, the sealing element can be used on its own or in combination with inner and/or outer rings.
| Items | Data | ||||
| Materials Metal Strip | Teel - 1.4301, 1.4401, 1.4541, 1.4571, Monel (NiCu30Fe) - 2.4360 | ||||
| Filling Material | Graphite 99,85% - operating temperature -200°C to +550°C , Graphite 98% - operating temperature -200°C to +400°C , PTFE - operating temperature -200°C to +250°C | ||||
| Material outer centering ring | Carbon steel - galvanised chromised or varnished, or in high-grade steel | ||||
| Material inner ring | Generally the material corresponds to that of the metal strip | ||||
| Gasket thickness | 3,2mm - 4,5mm - 6,5mm - 7,2mm | ||||
| Temperature (C) | -200~750 | ||||
| Operating pressure max. | 320 bar | ||||
①Pipe, valve, pump, thermal exchange, condensing tower, plain hole and man hole of flange, etc.
②Petrochemical, chemical, mechanical manufacturer, power station, metallurgy, shipbuilding, medical and pharmaceutical unclear power station and navigatio
Simply you can wholesale Spiral Wound Gasket with Inner & Outer Rings direct from manufacturers.
SUNPASS SEALING i a leading manufacturer in Sealing and Insulation in China. Production & Service 7*24 . Sunpass is a famous Chinese brand and Spiral Wound Gasket with Inner & Outer Rings suppliers known by the world since 2000.
