TOP SEALING Aramid Fiber Yarn 6500Y possesses outstanding properties of high strength, high modulus, high temperature resistance and flame resistance. Versatile and strong.
Kevlar fiber yarn has advantages of relative low density, fatigue resistance, tear and shear resistance, dimension stability. It has irreplaceable position in areas like personal protection, aerospace, electrical communication, and etc.
| Property | Value | ||
| English | Metric | ||
| Density | 0.052ib/ft3 | 1.44g/cm3 | |
| Model Number | — |
6500Y, 1500D/3000D-9000D |
|
| Fineness | — | 1.5D/840D/1000D/1500D | |
| Regain | 4±2%(20°C×65%R.H.) | ||
| Classification\Description | unit | KEVLAR® 29 | KEVLAR® 49 |
| Type | denier | 1500 | 1140 |
| dtex | 1670 | 1270 | |
| Moisture Levels | |||
| As Shipped | % | 7 | 3.5 |
| Equilibrium from Bone-Dry Yarn | % | 4.5 | 3.5 |
| Tensile Properties | |||
| Breaking Strength | lb | 76 | 59.3 |
| (N) | 338 | 264 | |
| Breaking Tenacity | g/d | 23 | 23.6 |
| (cN/tex) | 203 | 208 | |
| Tensile Modulus | g/d | 555 | 885 |
| (cN/tex) | 4900 | 7810 | |
| Elongation at Break | % | 3.6 | 2.4 |
| Temperature Range for Long-Term Use in Air | °F | 300-350 | 300-350 |
| (°C) | (149-177) | (149-177) | |
| Heat of Combustion | BTU/lb | 15000 | 15000 |
| (Joule/kg) | (35 x 106) | (35 x 106) |
1.Reinforcement materials
2.Personal protection
3.Composite materials
4.Friction sealing
5.Sports instruments and others
Simply you can wholesale Aramid Fiber Yarn direct from manufacturers.
1.High strength
2.High modulus
3.Chemically inert
4.Toughness and thermal stability
SUNPASS SEALING i a leading manufacturer in Sealing and Insulation in China. Production & Service 7*24 . Sunpass is a famous Chinese brand and Aramid Fiber Yarn suppliers known by the world since 2000.
