Porous PTFE Manufacturers

Porous PTFE

Description:

Porous PTFE is a unique form of PTFE that possesses a porous structure. It is created by introducing microscopic pores into the PTFE material during the manufacturing process. This results in a material with a network of interconnected voids or pores throughout its structure,specifically they are a mixture of different particle size distributions and hardness degrees to achieve the desired level of porosity.

Furthermore, using a combination of specially developed starting raw materials and taking advantage of the up-to-date technologies and know how, sunpass is able to supply different grades of porous PTFE powders, characterized by controlled pore size and distribution, permeability and water intrusion pressure (WIP). Sunpass technical assistance can give the best support in the designing of the final required characteristics and can offer tailor-made specific porous powders upon request.

Porous PTFE

Detail Image

Product Details

Items Data
Air flow rates up to 20 l/hr/cm² at 20 mbar
Water intrusion pressure (WIP) up to 1.2 bar
Average pore diameter up to 50 μm
Specific gravity 1.35-1.7 g/cm3
Tensile strength (CD) 4-8 MPa
Elongation at break (CD) 40-80%

More Styles

Application Data
Advantages
Video
Comparison Vision

Porous PTFE is mainly used for the production of filters (dust and water purification filters as well as precision filters for medical/clinical and life science applications ), optical parts (reflectors, spectrometers, photometers), acoustic / sound dampening components (wind screens for microphones, air regulator for speakers) and electrical / electronic insulating items.

Simply you can wholesale Porous PTFE direct from manufacturers.

Professional Manufacturer

SUNPASS SEALING i a leading manufacturer in Sealing and Insulation in China. Production & Service 7*24 . Sunpass is a famous Chinese brand and Porous PTFE suppliers known by the world since 2000.
