SILICONE COATED FIBERGLASS SLEEVING

Description:

TOP SEALING SILICONE COATED FIBERGLASS SLEEVING are heavily coated with iron oxide red silicone rubber, the coated sleeves shed molten metal splash and withstand intense heat and flame, making them ideal solution for heat protection for hoses, cable and tubing in a variety of hostile environments.

Detail Image

Product Details

Property	Description	Value
Property	Description	English	Metric
Hardness	30 Durometer, Shore A	-	-
Operating Temperature	-	500°F	260°C
Tensile Strength	-	>1000psi	>69bar
Tear Strength	-	150ppi	10bar
Elongation	-	>600%
100% Modulus	-	300psi	20bar
Compression Set	22 hrs at 350℉ (177°C)	>8%
Resistance to	Ozone	Excellent
	Corona	Excellent
	Radiation	Excellent
	Sunlight	Excellent
	Fungus	Excellent

More Styles

Application Data

Advantages

Video

Comparison Vision

Description\ Item		Silicone Coated Fiberglass Sleeve
Inner Diameter	English	0.3-4inch
	Metric	8.5-101mm
External Diameter	English	0.5-5inch
	Metric	12.5-112mm
Wall Thickness	English	0.1-0.2inch
	Metric	1.8-5.5mm
Length	English	393-472inch
	Metric	10-12m
Weight per Roll	English	3-48ib
	Metric	1.45-21.8kg
Color		Red

Simply you can wholesale SILICONE COATED FIBERGLASS SLEEVING direct from manufacturers.

Professional Manufacturer

SUNPASS SEALING i a leading manufacturer in Sealing and Insulation in China. Production & Service 7*24 . Sunpass is a famous Chinese brand and SILICONE COATED FIBERGLASS SLEEVING suppliers known by the world since 2000.
