4 TRUCKES 24 CARRIERS SQUARE MACHINE Manufacturers

Home / Products / Tools and Machine / Normal Type Gland Packing Braiding Machine / 4 TRUCKES 24 CARRIERS SQUARE MACHINE

4 TRUCKES 24 CARRIERS SQUARE MACHINE

Description:

4 TRUCKES 24 CARRIERS SQUARE MACHINE

Detail Image

Application Data
Advantages
Video
Comparison Vision
Machine Size(mm) 1700*1700*2300
Working Table Size(mm) 1200*1200
Motor Power 1.5kw(50Hz 380v)
Carrier Speed 25m/minute
Spindle Speed 280RPM/minute
Weaving Range 8*8--40*40
Weaving Speed Stepless Control
Yarn Tube Volume 68*130 68*160
Proposed Hammer Choice 0.4kg 0.6kg
Whole Machine Weight 1300kg
Main Horn Using wear resistant ductile iron
Remarks: The backplane is designed for outside circle-shaped with flat and gear. Waste drops down automatically. Especially suited for multi-dust material such as graphite and so on.

Simply you can wholesale 4 TRUCKES 24 CARRIERS SQUARE MACHINE direct from manufacturers.

Professional Manufacturer

SUNPASS SEALING i a leading manufacturer in Sealing and Insulation in China. Production & Service 7*24 . Sunpass is a famous Chinese brand and 4 TRUCKES 24 CARRIERS SQUARE MACHINE suppliers known by the world since 2000.
